Description
The Revelation Mini Patch Cable is built around our smallest pancake connector: a black cap engraved with the Revelation Cable Co. logo, finished with black heat shrink for solid strain relief. At 0.69 × 1.11″ (17.4 × 28.3mm), it has nearly the same footprint as a SquarePlug SP400, at a lower price, and it sits just 0.35″ (8.9mm) off the jack. That makes it the patch cable for tight pedalboards, where every pedal needs to sit as close as possible to the next.
Build it three ways, all for the same price: mini pancake to mini pancake, mini pancake to short straight, or short straight to short straight. Our short straight connector is only 1.10″ (27.9mm) long with a 0.51″ (12.9mm) round body, which makes it the right choice for switchers, loopers, and pedals where the jacks sit close together. Mini pancake to short straight is the classic pairing for switching systems: the pancake sits flat at the pedal, and the short straight fits the tight jack rows on the switcher.
Mogami 2319 has been the standard pedalboard patch cable for years. At 0.197″ (5mm), it’s a snug fit for the Mini pancake, and its spiral shield and PVC jacket make it flexible and dependable. Its capacitance of 47.3 pF/ft (155 pF/m) is higher than some cables in its class, but across typical pedalboard lengths it keeps high-frequency rolloff to a minimum.
Van Damme Unbalanced Pro-Patch is the lower-capacitance choice. At 27.4 pF/ft (90 pF/m), it pushes the resonant peak higher and keeps your top end open on longer runs. It’s slimmer at 0.178″ (4.5mm), and its PVC-neoprene composite jacket and 24AWG conductor make it exceptionally flexible.
Every cable is soldered by hand with lead-free, RoHS compliant silver solder, tested before it ships, and backed by our lifetime warranty.
Want a larger pancake? The Revelation Patch Cable uses our full-size connector. Want colour? The Revelation Mini Patch Cable on BTPA CA-0678 comes in seven jacket colours.
